- Three-level topology with conversion efficiency up to 98.5%; intelligent charge/discharge control with constant power, constant voltage, and constant current modes; supports DC voltage component detection and control functions.
- Supports 1.1x long-term overload and 1.2x short-term overload; high-frequency design reduces DC bus ripple for longer service life; IP66 protection rating for harsh environment adaptability.
- Integrated high-voltage junction box design; deep integration of PCS and BMS; modular design supports parallel operation of multiple units; supports wall-mounted and rack-mounted installation.
- Rated Power: 100/115/125kW
- DC Side Operating Voltage Range: 650Vdc–1000Vdc
- Rated Output Voltage: 400Vac (-20%~+15%)
- Dimensions (W×H×D): 800×250×900mm, 800×250×1060mm
- Weight: 97.5kg, 112.5kg
