- Three-level topology with conversion efficiency up to 99%, superior power quality, and strong grid adaptability; supports black start, grid-forming control, inertia response, primary frequency regulation, virtual impedance, and continuous high/low voltage ride-through capabilities.
- Intelligent liquid cooling with temperature control; supports cloud platform management.
- Supports communication protocols including MODBUS-TCP, CAN2.0B, and IEC61850.
- Visualized PCS operating status with online monitoring capability.
- Carrier synchronization reduces circulating current and interference during parallel operation; liquid cooling system with IP66 protection rating and low noise; operates across a wide temperature range in extreme environments with no derating at 50°C ambient temperature.
- High power density, compatible with AC/DC integrated design; adapted for next-generation 500/600+Ah large-capacity cell energy storage systems with one-cluster-one-management architecture. Modular design supports ≥16 AC-side parallel units.
- Rated Power: 430kW
- DC Side Operating Voltage Range: 1000Vdc–1500Vdc
- Rated Output Voltage: 690Vac (-20%~+15%)
- Dimensions (W×H×D): 735×225×850mm
- Weight: 140kg
