- Intelligent string-type architecture delivers 8% increase in usable capacity.
- Three-level topology design with overall system cycling efficiency >90%. Liquid cooling temperature control design keeps battery pack temperature difference <3°C.
- CATL long-life LFP cells with cycle life ≥7000 cycles.
- Pack-level intelligent fire protection with intelligent explosion-vent window design.
- Supports off-grid operation to provide backup power for critical loads.
- All-in-one design, grid-connected upon installation with no commissioning required.
- Modular plug-and-play expansion supports up to 20 units in parallel; 0.4kV low-voltage grid connection for efficient delivery.
- Cell Type: LFP/280Ah, LFP/314Ah
- Rated Battery Energy: 239.96kWh, 261.24kWh
- Rated Output Power: 115kW, 125kW
- Rated Output Voltage: 400Vac
- Protection Rating: IP55
