- Intelligent string-type architecture delivers 8% increase in usable capacity.
- Three-level topology design with overall system cycling efficiency >90%.
- Liquid cooling temperature control design keeps battery pack temperature difference <3°C.
- CATL long-life LFP cells with cycle life ≥7000 cycles.
- Three-level fire protection linkage: thermal runaway detection + perfluorohexanone + water spray.
- Independent compartment design for electrical and battery compartments prevents thermal runaway propagation.
- Supports off-grid operation to provide backup power for critical loads.
- All-in-one design, grid-connected upon installation with no commissioning required.
- Intelligent string-type balancing architecture supports phased investment and supplemental charging.
- Cell Type: LFP/314Ah
- Rated Battery Energy: 2089.984kWh
- Rated Output Power: 1000kW
- Rated Output Voltage: 400Vac
- Maximum System Efficiency: 90%
- Protection Rating: IP54
