- For inner layer hole registration process
- Starting the R&D for PE punch and Pin lam technology from 1986
- Four cameras (ECP4000), 8 cameras (ECP8000) for double layers registration inspection
- Option to choose the thickness from 1-20mil,21-40mil at the same model for thin core.
- Choose the punch size after input in PC, Punch Position Accuracy: ±0.5mil (0.0127mm) X or Y position to datum axis
- Punch Position Repeatability: ±0.3mil (0.00762mm) punch position measurements
- Hole Size/layout: customized
- Through-Put: 5-6 panels per minute (PI) / 7 panels per minute (FR4)
- Win 10 OS, easy to meet MES requirements
- Best operation and accuracy performance in the field .
