- Laser type: UV+CO2
- Wavelength: UV 355nm+CO2 9.4um
- Max. Power: UV>20W@90kHz;CO2 >300W
- Working Area：660 × 813 mm (26”× 32”)
- X/Y Feeding speed：50 m/min
- X/Y Positioning accuracy：±3 μm
- Galvano Scanning field: 50×50mm (Option: 35×35mm)
- Galvano Positioning accuracy：±10 μm
- Hole Diameter: CO2 : 75~180μm/UV : >35μm
