Features:
- High-speed and precision for efficient operations.
- Compact design suitable for limited spaces.
- Flexible reach and payload capacity for customization.
- User-friendly programming interface for ease of use.
- Advanced motion control for smooth and precise movement.
- Integrated vision systems for visual recognition and inspection.
- Easy integration and connectivity with other automation equipment.
- Safety features prioritizing operator and equipment safety.

Specification :
- Arm length: 225mm(X-axis), 175mm(Y-axis), 150mm(Z-axis)
- Rotation angle: +/-132 °(X-axis), +/-150 °(Y-axis), +/-360 °(R-axis)
- AC servo motor output: 200W(X-axis), 100W (Y-axis,Z-axis,R-axis)
- Repeatability : +/-0.01mm (X-axis,Y-axis, Z-axis) , +/-0.01 °(R-axis)
- Max. speed: 6 m/s(X-axis,Y-axis), 1.1 m/s(Z-axis), 2600 °/sec(R-axis)
- Maximum payload : 4 kg (Standard)
- Standard cycle time (with 2kg payload) : 0.41 sec
- R-axis tolerable moment of inertia: 0.05 kgm2
- User wiring : 0.2 sq × 10 wires
- User tubing (Outer diameter) : ϕ 4 × 3
- Travel limit : Soft limit, Mechanical stopper (X,Y,Z axis)
- Robot cable length : 3.5m (Standard)
- Weight : 17 kg
