Features:
- Patented different color alignment system
- Automatic reflow and mechanism for time and manpower savings
- High precision CSP/BGA rework equipment
- Using new control system of Industrial Microprocessor
- Fast check on 99 sets of profile memory

Specification :
Main Voltage: 220 ±10V AC
Power Consumption: Max. 6100W
Preset Temp. of Top: 50 ºC ~ 399 ºC (122ºF ~ 750) ºF)
Preset Temp. of Bottom: 50 ºC ~ 399 ºC (122ºF ~ 750 ºF)
Top Heater: 1000W
Bottom Heater: 1000/3000/5000W(Adjustable)
Air Spouting: 250 l/min Max. (Adjustable)
Vacuum Pump: 420mm Hg Max.
Working Lamp: 5 W 12V
P.C Board Size Capacity: 600mm x 460 mm Option:(600mmx680mm)
Applicable Devices: Max. 80mm x 80mm
Vision Magnification: Standard up to 20x. Option 40x, 60x
Dimensions: 62(W) x 62(H) x 70(D)cm
Weight: 98kg
